HB-101-2, 4
페이지 정보
본문
| Model | HB-101-2, 4 |
|---|---|
| Application | Various microorganism culture, cell culture, incubation test, germination test, constant temperature test etc. |
Application
Various microorganism culture, cell culture, incubation test, germination test, constant temperature test etc.
Feature
Precise temperature control is possible with the use of a digital P.I.D controller.
The inner door made of tempered glass allows a user to inspect the interior of the equipment.
Double packing ensures the gas tightness.
The temperature is maintained uniformly through the forced circulation method.
A device to prevent overheating prevention device is attached to prevent abnormal overheating of the device.
Computer-aided design (CAD) and computer-aided manufacturing (CAM).
Function
Timer Control
Auto Tuning
PID controller
Temp. Adjust
A password function
Back-up Device
Specification
| Model | HB-101-2 | HB-101-4 |
| Dimension (in) | 500x500x100(h)mm x 2room | 500x500x500(h)mm x 4room |
| Dimension (out) | 1280x720x1370(h)mm | 1320x720x1560(h)mm |
| Temp. Range | Ambient +5℃ to 70℃ | Ambient +5℃ to 70℃ |
| Compressor | None | None |
| Temp. Controller | Digital P.I.D controller(auto tuning) x 4room | |
| Temp. Accuracy | ± 0.1℃ at 20℃ | |
| Temp. Sensor | PT-100Ω, 0.15 grade | |
| Timer | Digital timer 99hr 59min, or infinity | |
| Capacity | 250 liter × 2room/total 500 liter | 125 liter × 4room/total 500 liter |
| Circulation fan | Internal convection fan | |
| Cooling system | On/off auto type | |
| Shelves | 3ea / each chamber, adjustable type | |
| Material (in) | Stainless steel polishing plate | |
| Material (out) | Scp-1 with powder coating | |
| Door | Double door, tempered glass inner door | |
| Safety device | Hydraulic temperature controller | |
| Defrost | Automatic defrost system | |
| Power (AC 220v, 60hz) | 600w, 3a, 250kg | 1.2㎾, 350kg |
* Optional accessories : 10 step program control (LCD display)
