Model HB-305M
Application Used for plant tissue culture, breeding, purification, microorganism culture, microalgae culture etc.

Application

Used for plant tissue culture, breeding, purification, microorganism culture, microalgae culture etc.

Feature

Temperature can be maintained precisely with a digital PID controller.
Various temperature conditions can be set with 2-step temperature change experiment and 10-step program.
A 24-hour timer allows the control of the intensity of illumination day and night.
Since 3~5 chambers can be set up and operated at different temperatures, the system is suitable for comparative experiments, and various experiment results can be obtained in a short time.
Through a glass door, a user may inspect the experiment condition inside.
Each chamber can be set at a different temperature under the same illumination. The temperature of a chamber should not deviate more than 7℃ from the temperature of the adjacent chamber.

Specification

Model HB-305S HB-305M
Chamber 3 room 5 room
Dimension(in) 500x500x330(h)mmx3room 500x500x230(h)mmx5room
Dimension(out) 680x820x1790(h)mm 680x830x1930(h)mm
Capacity 250 liter 300 liter
Illumination F.L 30w x 6ea F.L 40w x 6ea
Temp. Controller Digital P.I.D controllerx3ea Digital P.I.D controllerx5ea
Temp. Range 0℃ to 60℃(light on : 10℃ to 60℃) r
Temp. Accuracy ± 0.2℃ at 25℃
Illumination control Day & night program control
Material(in) Stainless steel polishing plate
Material(out) Scp-1 with powder coating
Door Glass inner door, magnetic packing outer door
Safety device Over limit temp s/w
Power (AC 220v, 60hz) 2kw 3kw
