Model HB-509C
Application Substances can be dried in an aseptic, dust-free state. The test of semiconductors and electronic parts at constant temperatures and the heat resistance test may be performed, and various experiment equipment, glassware etc. may be dried in a clean state.

Application

Substances can be dried in an aseptic, dust-free state. The test of semiconductors and electronic parts at constant temperatures and the heat resistance test may be performed, and various experiment equipment, glassware etc. may be dried in a clean state.

Feature

PID ControllerThe controller with built-in auto-tuning allows precise temperature control. If a user needs to conduct an experiment with temperature changes, the 10-step program and repeated experiments are possible (program model).
Fan MotorSmooth circulation is possible only if an appropriate amount of air pressure is applied to the filter. A low-noise, high-efficiency special fan is installed to maintain the cleanness and the uniform temperature distribution.
StructureThe interior is made of highly durable stainless steel 304 polishing plate. The structure is such that the air passing through the filter is circulated. The system can be kept clean, and the repair and the maintenance are easy.
FilterBased on the purpose of the experiment, a user can select between the medium filter and HEPA filter to maintain a high degree of cleanness.

Specification

Model HB-509C
Convection type Convection type
Temp. Controller Digital P.I.D controller
Temp. Range Ambient +5℃ to 200℃
Temp. Accuracy ± 1℃ at 100℃
Timer Digital timer 99hr 59min, or infinity
Dimension 600×600×600(h)㎜
Capacity 216 liter
Filter Hepa filter
Material(in) Stainless steel(sus304)
Material(out) Scp-1 with powder coating
Shelves Stainless steel 304 3ea
Door Silicon packing door with window
Safety device Over load s/w
Power (AC 220v, 60hz) 1.8kw
